4 way 2.4G Wireless Car Rearview System with quad image display

EV-7010MQW

Delivery

FOB

minimum order

Supply Ability

1000000 / Year

Quantity:

Contact Now

add to cart

2.4G Digital Wireless Quad Monitor With RVR Recording,Support 4 channel 2.4 G wireless videos input, support multiple split screen switching with reverse line.

Model number	EV-7010MQW
Resolution	800R.G.B480
Backlight	LED, illuminance 300 cd/m²
Effective pixels	VGA：640X480/D1：720X480
Video frame rate	VGA:30f/s/D1: 25f/s
Viewing angle	up—50°，down—70°，left—70°，right—70°
Working Tempture	-20~60 ºC
Storage temperature	-30~85 ºC
Power supply	9-30V
Booting	within 2S
Delay	120mS
Current consumption	TYPE:300mA, Max.380mA
OSD control	contrast imge setting mirror or non mirror adjustable menu setting Real time recording and video playback
Maximum current	＜5W
AV input	Support 4 channel 2.4 G wireless videos input
Image display	Support multiple split screen switching
Trigger control	4 channel trigger control with reverse line
Imge Recording	Support 128G SD
Rotating frequency	2400 ~ 2483.5MHz *
Video frame rate	VGA:30f/s/D1: 25f/s
Adjustable method	FSK/GFSK
System	PAL/NTSC
Transmission bandwidth	3Mbps
Receiving sensitivity	-88dBm@4MHZ
Antenna input and output impedance	50Ω, Typ.
Spread spectrum	frequency hopping
2.4G wireless transmitting distance	150M in open area
Shockproof Level	4G
Audio	4 channel audio input
Power line	5.5 female / paired switch
Specifications	Model No.：EV-127ADW
Image sensor	1/4″CMOS OV7725
Effective pixels	640*480 pixels 0.3 million
Viewing angle	100 degree
Night vision visible range	About 3M
Audio input	High sensitivity, -36DB microphone
Waterproof level	IP68
Shockproof level	4G
2.4G wireless transmitting distance	150M in open area
Power supply	DC 12-24V
Power consumption	＜5W
Maximum current	＜250mA
Working temperature	-20℃ to 70℃
